Aquafog Jaybird GT 500-HS-115 Fan

Hanging Sump Fog System

The GT 500 Hanging Sump is a ready-to-operate unit designed for interior humidification, evaporative cooling, and chemical fogging. Components are UV stabilized and suitable for outdoor use.

This centrifugal atomizer has a rear-feed blade system that produces billions of tiny, fog-like particles that evaporate quickly. A hydrophilic front guard helps keep floors dry. The unit’s sump recycles wastewater and conserves water, making this unit great for use in drought-prone areas. The GT Hanging Sump uses a float valve to maintain the water level in the tank, a submersible pump to send water to the fogging head, and ball valve to control the fogging output.

The Hanging Sump comes equipped with an on/off power switch, 20’ of water line, and a 15’ power cord with plug. Units hang by either a single U-bolt or a universal mounting bolt.

  • Nozzle-Free Atomization
  • Up to 5.5 GPH Fogging Output
  • 44,500 Btu/h (Evap. Cooling)
  • Recycles Wastewater
  • Arrives Fully Assembled
  • Voltage: 115V 60Hz 1Ph

Features:

Standard Controls

GT 500 Hanging Sump comes outfitted for manual operation. The system can be automated by adding a control package.

  • 5.5 GPH Max. Net Output
  • Water-tight Switch Box
  • 3 Gallon Sump w/Easy Access Lid
  • Garden Hose Connect

A 1/4 turn ball valve controls the fogging output. Lower flow rates are generally used in applications requiring drier fog.

Flow Rate with Related Applications:

Up to 15 GPH Up to 10 GPH Up to 5 GPH
  • Ag/Horticulture
  • Concrete Curing
  • Evaporative Cooling
  • Mushrooms
  • Manufacturing Plant
  • Wine/Barrel Storage
  • Wood/Lumber/Paper
  • Mfg Dust/Static
  • Textile Plant
  • Fumigation

Jaybird’s Rear-Feed Blade

Our exclusive blade design is a significant product development, enhancing reliability and performance.

ABB Wash-Down-Duty Motor

  • Industrial grade
  • For use around water

Hydrophilic Guard

The front guard is designed to meet OSHA fan guard requirements and wick away water.

  • Meets OSHA 1/2” Spacing Requirement
  • Stainless Steel

Specifications:

Overall Dimensions: Diameter 21" / 53.3 cm
Depth 17.5"/ 44.5 cm
Height 25" / 63.5 cm
Unit Weight: 38 lbs / 17.2 kg
Propulsions Distance: 25 - 30 ft / 7.6 -9.1 m
Noise @ 10 ft Distance: 68 - 70 dB(A)
Average Particle Size: 5-10 microns @ low volume
30 microns @ high volume
Max. Fogging Output: 5.5 GPH - 60Hz
CFM: 1,800
Cooling Capacity: 44,500 Btu/h @ 60Hz
Tank Capacity: 3 gallon (US) / 11.3 liter
Operation: Continuous duty capacity
Energy Consumption: 1/4 HP - 3.6 amps @ 115V
Shipping Weight: 55 lbs / 25 kg
Shipping Dimensions: 19"x 24"x 38"
48.3 cm x 61 cm x 96.5 cm
Environment: Endure temperatures from 33° to 160° F
Indoors / outdoors
Humidity to 100% RH
UV stabilized & impact resistant

Discover the Accessories Available for the GT 500-HS-115 Fan:

Oscillator:

Control Packages:

Stands & Mounts:

Humidity & Temperature Measure:
