Waterite Blackmaxx RB8 60,000GPD RO System

WateriteSKU: HY-451860

Sale price$ 50,259.95
🍃 Earn 50259 GrowClub points worth $502.6 off your next order
 More payment options
  • Free Shipping over $149.99 Canada-wide
  • Ships discreetly
  • Ships in 3-5 business days
Bulk / Commercial Discounts and Rebates

Email us or call 888-349-0321 TODAY!

(Special order  1-4 weeks)

RB8 Blackmaxx systems include as standard features stainless drive pumps, stainless jumbo prefilter housing, FRP membrane housings, stainless steel piping, auto-flush, digital flow and TDS monitors, integrated system controller, CIP-ready (CIP not included) and with factory-programmed PLC. Everything to assure simplicity, dependability and rugged performance.

Specifications

  • Type: Extra-low pressure RO system, 8” spiral wound membranes, recirculation loop, pre-filter, skid mounted
  • Voltage: 208/230 VAC/60Hz, 3PH
  • Service amps: 208/230 VAC 3PH - 25.6/23
  • Feed water pressure: 40 psi minimum, 65 psi maximum
  • Feed water temp: 40º C maximum
  • Frame colour: Gloss White epoxy powder coat
  • Frame material: Mild steel 1.5” X 1.5” X 10 ga. rectangular tube, welded
  • Nominal operating pressure: 135 psi (9.4 bar) pre-membrane
  • Membrane: MAX®, spiral wound TFC, BME8040SXL, 10,000 USGPD permeate (+/-15%) @ 500 mg/l NaCl, 115 psi, 25ºC feed 7.5 pH and 15% recovery
  • Inlet valve: 220VAC/60Hz, SST Actuated ball valve, Manual override with visual valve position indicator, Two dry contact auxiliary limit switches used to confirm valve open/closed position 1.25” FNPT 20k/30k, 1.5” FNPT 40k/60k, 2.0” FNPT 80k/100k/120k
  • Flush solenoid: 220VAC/60Hz, normally closed, zero differential, brass 1.25” FNPT 20k/30k, 1.5” FNPT 40k-120k, 80k/100k/120k
  • Pressure switches: SPDT snap action; single circuit 5 Amp @ 125/250 VAC (Class BB microswitch - standard) ± 2% of full range
  • Drive pump motor: 208/230VAC/60Hz 3PH, TEFC, type 215TC frame, 3450 RPM, threaded shaft, ball bearing (Unless otherwise specified)
  • Drive pump: Multi-stage 306SS vertical booster pumps, flanged stainless discharge, housing and bracket, stainless impellers and stages, SS bearings, wear rings, couplings and pump shaft
  • Operation flow rate (35 psi feed): 35.8 USGPM
  • Concentrate/recirculation valve: Butterfly1.0” Wafer cast body, EPDM seals, sst disc, gear drive operator
  • System fittings: Schedule 80 PVC
  • Low pressure fittings: Brass Presslok standard pressure compression
  • Low pressure tubing: High pressure 1/4” MDPE, black
  • Pre-filtration housing: JF Series 304 SS Jumbo Filter, 100 psi rated, o-ring seated with band clamp closure, 2” flanged inlet/outlet, full flow, 40 USGPM (20K) 90 USGPM (30K/40k) 130 USGPM (60k-120K))
  • Filter cartridges: Excelpure Jumbo Filter Cartridges 10” (HHF405) 20K/, 20” (HHF905) 30K/40K or 30” (HHF1705) 80K-120K pleated polypropylene, 5-micron
  • Membrane housing: 8040/8080/80120 FRP, anti-telescoping cages, 1½”/2” Victaulic quad-feed ports, 1” fnpt permeate port, 300 psi rating, product adapters, straps and saddles
  • Pressure gauges: Glycerin filled, stainless b o d y , 2.5’’. (2X) 0-100 psi feed water pressure differential, (2X) 0-200 psi system pressure, trans-membrane
  • Flow meters: (2) Create Model 8350 Digital Display Flow Transmitters, Paddle Wheel Style Sensors, and Installation Tees. 24VDC isolated output, 0-10, 0-20, 4-20 ma, DC current, RS485 for remote monitoring
  • RO control panel: Moeller PLC- Pre Programmed High/Low Pressure Protection, Tank Full Indication. Operational indication of Inlet Pump, Inlet valve, Main Pump, Flush Valve, and Conductivity Over Limit Set Point. Single Conductivity Probe On Permeate 0-10/ 0-100/0- 1000 TDS. 0.75” MNPT. Automatic Temperature Compensation 220VAC 1ph (+/-15%)
  • Electrical cabinet: FRP, Nema 4 Enclosure, CSA, UL approved
  • Permeate production rate: 11.0 USGPM (41.6 LPM)
  • Waste production rate: 7.3 USGPM (27.6 LPM)
  • TDS: < 2200 TDS
  • Hardness: < 6 gpg (103 mg/l)
  • Total iron: < .05 ppm
  • Tannin: < .5 ppm
  • Chlore: < .1 ppm
  • pH: 5.5 – 9.5
  • Organic/microbiological activity: 0
  • Manganese: <. 05 ppm
  • Hydrogen sulphide: 0
  • Turbidity: SDI < 5.0 / NTU < 1.0
  • Feed water requirements (GPM @40-60 psi 1.5"): 18.3 USGPM (69.2 LPM)

Dimensions & weight

  • Dimensions: 67.5" H x 64.75" W x 32" D
  • Weight: 835 lbs
